INPUT

0-10V DC / 4-20MA

CONTROL

ZERO CROSS OUTPUT, PHASE SHIFT OUTPUT (WITHOUT NEUTRAL)

PHASE SHIFT

< 175 DEGREE

MODE

COMBINE TRIGGER MODE OF PULSE AND OPTOCOUPLER

LOAD

SUITABLE FOR RESISTIVE LOAD FOR 1 PHASE / 3 PHASE

WIRING

SUPPORT STAR WITHOUT NEUTRAL / DELTA WIRING

ANTI-INTERFERENCE

STRONG ANTI-INTERFERENCE FUNCTION AND PASS 1800 V COMMON MODE AND DIFFERENTIAL MODE EXPERIMENT

DISPLAY / KEYBOARD

4 DIGIT DISPLAY WITH 4 KEYS TO PROGRAM

INDICATION

POWER INDICATION / RUN INDICATION / ON LINE DISPLAY FOR RUNNING OUTPUT ERROR MESSAGE INDICATION

PROTECTION

STOP-PHASE PROTECTION / SIGNAL LOSS DETECTION / OVER HEAT PROTECTION

OUTPUT

1 RELAY OUTPUT FOR ERROR DETECTION

SOFT-START

SUPPORT SOFT START FUNCTION WITH ADJUSTABLE TIME LIMIT

FUNCTION

SUPPORT POWER LIMIT FUNCTION

COMMUNICATION

RS - 485 (OPTIONAL)

PROGRAMMABLE FUNCTION

MAX. OUTPUT CAN BE LIMIT THROUGH PROGRAMMING

COOLING

NATURAL AND FORCED AIR COOLING AS PER LOAD CAPACITY

SUPPLY

AC 85~265V, 50 HZ

AMBIENT TEMPERATURE

0°C ~ 50°C
