CONNECTION

3PHASE -3W / 3PHASE -4W

RANGE LIMIT

0 - 500 VAC / 0 - 999 AMP

INPUT

5 AMP CT SELECTABLE / VOLT : 0-500 VAC

FUNCTION

OVER / UNDER VOLTAGE, SINGLE PHASE PROTECTION, PHASE SEQUENCE, PHASE FAILURE, OVER / UNDER CURRENT, UNBALANCE CURRENT, OVER / UNDER FREQUENCY, LOCK ROTOR, SHORT CIRCUIT PROTECTION

OUTPUT

2 RELAY - HEALTHY / FAULT CONDITION

DISPLAY

3 DIGIT 3 ROW

KEYBOARD

FEATHER TOUCH KEYPAD

POWER SUPPLY

230 VAC, ±10 %, 50 Hz
