SETTING

PUSH TO SET CONTROLLER , KNOB SETTING, BLIND CONTROLLER

SENSOR

T/C : J,K OR RTD: PT-100/3 WIRE , TC : J TYPE , TC : J TYPE

RANGE LIMIT

J (0-400°C), K (0-1200°C) PT-100 (0 to 400 °C) , (0-400°C) ,(0-400°C)

ACCURACY

± 0.5 % OF FS

RESOLUTION

1°C FOR THERMOCOUPLE / 1°C FOR RTD

CONTROL ACTION

T.P OR ON-OFF FACTORY SET

NUMBER OF RELAY

1 RELAY OUTPUT

DISPLAY / COLOR

4 DIGIT SINGLE DISPLAY BRIGHT RED SEVEN SEGMENT DISPLAY

INDICATION

FOR RELAY STATUS / T/C OPEN INDICATION

MOUNTING

FLUSH PANEL MOUNTING WITH SIDE CLAMP

POWER SUPPLY

230 VAC, 50 - 60 Hz, ±10 %, > 5 VA
