FUNCTION

6 DIGIT COUNT TOTALISER - UP COUNTING, 6 DIGIT HOUR METER - UP COUNTING

RANGE LIMIT

0 - 999999 COUNT, 0 - 9999.59 HOUR / MIN.

INPUT

PROXY / 230 VAC / 24VDC ( SENSOR SUPPLY : 12 V DC / 30 mA ), 230 VAC PULSE / 24 VDC PULSE

INPUT SPEED

0 -10 KHz, NA

ACCURACY

± 1 COUNT, ± 0.1 MIN.

DISPLAY

6 DIGIT SINGLE DISPLAY, 6 DIGIT SINGLE DISPLAY

RESET

FRONT / BACK RESET, FRONT / BACK RESET

MEMORY

YES (NON-VOLATILE MEMORY), YES (NON-VOLATILE MEMORY)

POWER SUPPLY

230 VAC, ±10 %, 50 Hz, 230 VAC, ±10 %, 50 Hz
